Personal DVR WARD 500 is intended to ensure the personal safety during the performance of professional duties.
The DVR provides the following functions:
— Quality control
— The route and location in the exact time
— provides the provident basis in case of a dispute
— exercise the mental pressure to the intruder.
Technical description:
| Senor | CMOS HD Sensor OV4689 |
| Matrix size | 1/4” |
| Matrix Resolution | 4MP |
| Viewing angle | 130° horizontally |
| Infrared backlight sensitivity | When the backlight is off — no more than 1 Lux. When the backlight is on — 0 Lux |
| Night mode | Movable IR filter, IR illumination (automatic and manual switching), IR + LED illumination |
| Light range | WDR |
| Standards | NTSC, PAL |
| Identification Range | Up to 10 meters to see facial features |
| Video resolution | 1296p (3MP); 1080p (2MP); 720р (1 MP); 480р (0,4МP) |
| Write speed | 2304×1296/30p 1920×1080/30p 1280×720/30p 1280×720/60p 848×480/30p |
| Time-lapse | Arming mode — slow-motion recording no more than 1 frame / sec for recording continuous events |
| Prerecord mode | Buffering 10 sec. before forced recording |
| Video format | Н.264, MOV |
| Photo | JPG, 24Мрх1, taking pictures without interrupting the video recording |
| Multiple consecutive photos | Support the number of consecutive shots: 3/6/8 |
| Video segmentation | 10 to 30 minutes no more than 10 min |
| Stamp | Device ID、Police officer ID、Date and Time |
| Audio | Built-in microphone, synchronous audio recording, built-in speaker (audio signals / voice status comments) |
| Loop recording | The presence of automatic cyclic recording of information when filling the internal memory with the removal of the oldest segments of records. Protect important files from cyclic erasure |
| Internal memory | Non-removable built-in memory card max support 128GB class 10 |
| Power Recording time | 2304*1296 30P : 660min,1920*1080 30P 700min, 1280*720 30P 740min, 848*480 30P 780min |
| Memory full | Visual indicator, beep |
| Battery | Built-in, rechargeable, high-capacity lithium-ion 2850m Ah lithium battery, charging time 4 hours, power adapter with USB cable, car charger included |
| Charge indication | Diode and audible warning of low battery |
| Weight | 110g |
| Mount | clip for
Mounts on the lapel of clothes or on a pocket, rotates 360 ° |
| Body | Sealed shockproof body. Product serial number, the possibility of its removal or painting is excluded |
| Waterproof | IP66 |
| Temperature range | From -20 ° С to + 60 ° С |
| Maximum humidity | 85% |
| Interface | Micro USB 2.0 charging and data streaming together |
| View | On a Windows PC or using a terminal |
| Compatibility | with Windows operating system |
| Software functionality | To copy and view recorded information on a PC |
| Data protection | data protection against unauthorized access |
| Auto save | Automatically save current data before turning off the DVR or when the built-in battery is discharged |
| Use of terminal | Compatible with terminals, docking stations. |
| Dimensions | 77x53x25（mm） |
